Cylinder Flange Deep Groove Ball Bearings ABEC-5 Good Wear Resistant

    Buy cheap Cylinder Flange Deep Groove Ball Bearings ABEC-5 Good Wear Resistant from wholesalers

    Buy cheap Cylinder Flange Deep Groove Ball Bearings ABEC-5 Good Wear Resistant from wholesalers
    • Buy cheap Cylinder Flange Deep Groove Ball Bearings ABEC-5 Good Wear Resistant from wholesalers
    • Buy cheap Cylinder Flange Deep Groove Ball Bearings ABEC-5 Good Wear Resistant from wholesalers
    • Buy cheap Cylinder Flange Deep Groove Ball Bearings ABEC-5 Good Wear Resistant from wholesalers
    • Buy cheap Cylinder Flange Deep Groove Ball Bearings ABEC-5 Good Wear Resistant from wholesalers

    Cylinder Flange Deep Groove Ball Bearings ABEC-5 Good Wear Resistant

    Ask Lasest Price
    Brand Name : MCBB/ Customization/ Any famous brand
    Model Number : 6206
    Certification : CE
    Price : negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, Payment online by credit card, Direct RMB from aborad
    Supply Ability : 30,0000pcs/month
    Delivery Time : Within 7days after confirmation
    • Product Details
    • Company Profile

    Cylinder Flange Deep Groove Ball Bearings ABEC-5 Good Wear Resistant

    Cylinder Flange Deep Groove Ball Bearings ABEC-5 Good Wear Resistant


    Description,


    SKF bearing SKF 6206 6207 6208-2RS12Z / C2 / VA201 high speed precision high temperature SKF bearing.


    Ball bearing wheels, Specification,


    Bearing Model6206, 6206-2RS, 6206-ZZ
    d30mm
    D62mm
    B16mm
    D152.1mm
    Da max56.4mm
    d140mm
    da min35.6mm
    ra max1 mm
    r min1mm
    m0.195kg
    Cr20700 N Basic dynamic load rating, radial
    C0r11300 N Basic static load rating, radial
    nG14000 1/min Limit speed
    nB12000 1/min Reference speed
    Cur680 N Fatigue limit load, radial

    Deep groove ball bearings single row, Feature,


    1. High torque for low friction.


    2. Imported bearing material with high accuracy and long service life.


    3. The bearing has a high speed limit and is not easy to get hot.


    4. Imported materials improve precision


    6200 series deep groove ball bearing model,


    Bearing No.Size(mm)Weight(kg)
    620010*30*90.032
    620112*32*100.037
    620215*35*110.045
    620317*40*120.065
    620420*47*140.106
    620525*52*150.128
    630010*35*110.053
    630112*37*120.060
    630215*42*130.082
    630317*47*140.115
    630420*52*150.144

    Bearing Type
    Principal Dimensions
    (mm)
    Basic Load Ratings
    (KN)
    limiting Speeds
    (r/min)
    Reference weight
    (KG)
    d
    D
    B
    Cr
    Cor
    Crease
    Oil
    Wt
    6200
    10
    30
    7
    5.100
    2.390
    24000
    30000
    0.032
    6201
    12
    32
    10
    6.800
    3.050
    22000
    28000
    0.037
    6202
    15
    35
    11
    7.650
    3.750
    20000
    24000
    0.045
    6203
    17
    40
    12
    9.550
    4.800
    17000
    20000
    0.067
    6204
    20
    47
    14
    12.800
    6.600
    15000
    18000
    0.107
    6205
    25
    52
    15
    1.400
    7.850
    13000
    15000
    0.129
    6206
    30
    62
    16
    19.500
    11.300
    11000
    13000
    0.119
    6207
    35
    72
    17
    25.7
    15.4
    8800
    11000
    0.291
    6208
    40
    80
    18
    30.9
    19
    7800
    9700
    0.366
    6209
    45
    85
    19
    30.9
    19.4
    7200
    8900
    0.413
    6210
    50
    90
    20
    35.1
    23.3
    6700
    8300
    0.467
    6211
    55
    100
    21
    43.4
    29.3
    6100
    7500
    0.608
    6212
    60
    110
    22
    47.8
    33.1
    5500
    6800
    0.798
    6213
    65
    120
    23
    57.2
    40.2
    5100
    6300
    0.974
    6214
    70
    125
    24
    60.8
    45.1
    4800
    5900
    1.110
    6215
    75
    130
    25
    66.1
    49.6
    4600
    5700
    1.170
    6216
    80
    140
    26
    72.7
    53.1
    4300
    5300
    1.370


    Application,


    Bearing 6206 can also be used for: combined machine tool non-leakage pump cutting machine homogenization equipment reflow welding machine quilting machine milling machine cutting equipment medical gas shielded welding machine medical auxiliary equipment industrial sewing machine thread rolling machine seam equipment plasma welding machine Fabric inspection machine, bending machine, lace machine, energy saving welding machine.



    Action contact us now for its price list.
