SL18 1852-E Full Complement Cylindrical Roller Bearings SL181852-E

    Buy cheap SL18 1852-E Full Complement Cylindrical Roller Bearings SL181852-E from wholesalers

    Buy cheap SL18 1852-E Full Complement Cylindrical Roller Bearings SL181852-E from wholesalers
    • Buy cheap SL18 1852-E Full Complement Cylindrical Roller Bearings SL181852-E from wholesalers
    • Buy cheap SL18 1852-E Full Complement Cylindrical Roller Bearings SL181852-E from wholesalers

    SL18 1852-E Full Complement Cylindrical Roller Bearings SL181852-E

    Ask Lasest Price
    Brand Name : MCBB/ Customization/ Any famous brand
    Model Number : SL18 1852-E
    Certification : ISO9001:2008
    Price : 0.2USD
    Payment Terms : L/C, , T/T, Western Union, MoneyGram, Paypal, Payment online, RMB
    Supply Ability : 10000pcs/Month
    Delivery Time : Within 7days after confirmation
    • Product Details
    • Company Profile

    SL18 1852-E Full Complement Cylindrical Roller Bearings SL181852-E

    SL18 1852-E Full Complement cylindrical roller bearing SL181852-E


    SL181852-E Cylindrical Roller Bearing Description,


    1. Bearing type: Cylindrical roller bearing New model: SL181852-E Old model: SL181852 Inner diameter (mm): 260 Outer diameter (mm): 320 Width (mm): 28 Cylindrical roller bearings are generally only used to withstand radial loads.


    2. Compared with deep groove ball bearings of the same size, they have a larger radial load capacity, and the limiting speed is close to deep groove ball bearings.


    3. The processing requirements of the housing hole are high, allowing the inclination of the inner ring axis and the outer ring axis to be small (2 ° -4 °).


    5. If the two axis tilt exceeds the limit, the contact between the roller and the raceway of the ring will worsen, serious Affects the load capacity of the bearing and reduces the service life of the bearing.


    6. Therefore, if this type of bearing needs to be installed in the host component that bears the axial load, it can only be used under the premise that other types of bearings are used at the same time to bear the axial load.


    SKF cylinderical roller bearing, Specification,


    Germany

    Model

    d

    D

    H

    m

    SL181830

    150.00 mm

    190.00 mm

    20.00 mm

    1.3 KG

    SL181832

    160.00 mm

    200.00 mm

    20.00 mm

    1.45 KG

    SL181834

    170.00 mm

    215.00 mm

    22.00 mm

    1.85 KG

    SL181836

    180.00 mm

    225.00 mm

    22.00 mm

    2 KG

    SL181838

    190.00 mm

    240.00 mm

    24.00 mm

    2.45 KG

    SL181840

    200.00 mm

    250.00 mm

    24.00 mm

    2.57 KG

    SL181844

    220.00 mm

    270.00 mm

    24.00 mm

    2.8 KG

    SL181848-E

    240.00 mm

    300.00 mm

    28.00 mm

    4.29 KG

    SL181852-E

    260.00 mm

    320.00 mm

    28.00 mm

    4.61 KG

    SL181856-E

    280.00 mm

    350.00 mm

    33.00 mm

    6.89 KG

    SL181860-E

    300.00 mm

    380.00 mm

    38.00 mm

    9.79 KG

    SL181864-E

    320.00 mm

    400.00 mm

    38.00 mm

    10.36 KG

    SL181868-E

    340.00 mm

    420.00 mm

    38.00 mm

    10.93 KG

    SL181872-E

    360.00 mm

    440.00 mm

    38.00 mm

    11.49 KG

    SL181876-E

    380.00 mm

    480.00 mm

    46.00 mm

    18.87 KG

    SL181880-E

    400.00 mm

    500.00 mm

    46.00 mm

    19.81 KG

    SL181884-E

    420.00 mm

    520.00 mm

    46.00 mm

    20.6 KG

    SL181888-E

    440.00 mm

    540.00 mm

    46.00 mm

    21.54 KG

    SL181892-E-TB

    460.00 mm

    580.00 mm

    56.00 mm

    33.21 KG

    SL181896-E-TB

    480.00 mm

    600.00 mm

    56.00 mm

    34.53 KG


    Picture Show,


    Why choose us,


    NO MOQ, 1 PCS order quantity


    If you need, welcome contact us for price list.
