Anti Rust Housings Pillow Block Ball Bearing Low Friction UCFCS211
UCFCS211 Description,
The outer spherical bearing is spherical (universal rotation) bearing has the function of adjusting the center. When the new bearing product leaves the factory, the bearing and the bearing housing are not adjusted, which is a normal phenomenon. It can be corrected during installation and use.
Specification, split housing pillow block bearings,
Bearing Unit | Dimensions(mm) | Bearing No. | Housing | Housing | |||||||||||
NO. | No. | Wt (kg) | |||||||||||||
| a | p | e | i | s | j | k | g | f | z | Bi | n |
|
| |
UCFCS211-32 | 162 | 137 | 96.9 | 7 | 14 | 16 | 11 | 25 | 114 | 39.8 | 55.6 | 22.2 | UC211-32 | FCS211 | 2.72 |
UCFCS211-33 | UC211-33 | ||||||||||||||
UCFCS211-34 | UC211-34 | ||||||||||||||
UCFCS211-35 | UC211-35 | ||||||||||||||
UCFCS211 | UC211 |
UCFCS211 Feature, installing pillow block bearings,
1. Shaft fastening: 2 grub screws, inner ring extended on both sides.
2. Material: ultra clean AISI 52100 chrome steel
3. It is suitable for high loads and speeds, also in case of alternating direction of rotation.
4. Grease: Chevron SR1-2 or food industry FM222
5. Working Temperature range: -20°C to +120°C celsius
Why us?
NO MOQ, 1pcs is ok. Supporting 7days refund.
More model bearings,
Model NO. (Pillow block bearing) | Length(mm) | Width(mm) | Thickness | Weight(kg) |
UCP201 | 127 | 38 | 60.7 | 0.76 |
UCP202 | 127 | 38 | 60.7 | 0.74 |
UCP203 | 127 | 38 | 60.7 | 0.72 |
UCP204 | 127 | 38 | 64 | 0.7 |
UCP205 | 140 | 38 | 69.5 | 0.76 |
UCP206 | 160 | 44 | 82 | 1.25 |
UCP207 | 167 | 48 | 92 | 1.55 |
UCP208 | 180 | 52 | 98 | 1.9 |
UCP209 | 189 | 54 | 106 | 2.2 |
UCP210 | 204 | 57 | 112 | 2.75 |
UCP211 | 217 | 60 | 125 | 3.3 |
UCP212 | 238 | 66 | 137 | 4.7 |
UCP213 | 262 | 70 | 149 | 5.6 |
UCP214 | 266 | 72 | 155 | 6.6 |
UCP215 | 274 | 74 | 162 | 7.3 |
UCP216 | 292 | 78 | 174 | 9 |
UCP217 | 310 | 83 | 186 | 10.8 |
UCP218 | 326 | 88 | 198 | 13 |
UCP220 | 380 | 95 | 225 | 16 |
Pillow Block Ball Bearing Package,
1. Neutral industry package, single PP bag+signle color box+ hardness outer carton+ Pallet.
2. Per customer's require to packing.
3. Encomic Package, 5pcs/carton+Pallet
Action now, welcome contact us for price list. The following is our 24hours in service. Welcome to be our " VIP' customer to enjoy more special prices.
![]() |
